Veterianry Anesthesia Workstation
DA1200V8
Dolphinmed veterinary anesthesia workstation DA1200V8 with ventilator，suitable for animal hospital,pet clinical and animal laboratory,it can meet needs of general anesthesia and medical research on mice,dogs,cats,rabbits,monkeys,pigs,sheep and other animals,etc
Quantity
Dolphinmed veterinary anesthesia workstation DA1200V8 with ventilator，suitable for animal hospital,pet clinical and animal laboratory,it can meet needs of general anesthesia and medical research on mice,dogs,cats,rabbits,monkeys,pigs,sheep and other animals,etc
（veterinary anesthesia workstation）
Feature：
1.Applied to animals of different weights and sizes
2.The non-breathing circuit interface is designed at the front of the machine, which is convenient for anesthetizing small animals
3.With pressure, volume, manual and other breathing modes, meet different clinical needs
4.The built-in high-precision sensor and valve control technology ensure the safety, stability and accuracy of pressure, flow and volume monitoring and control
5.Equipped with high-precision anesthesia vaporizer, three-year warranty
6.Import of core parts and components from the international origin
7.Equipped with 8-inch high-definition touch screen
8.Triple visual and audio security alarm system to ensure safety during surgery
9.Built-in proportional valve control system
10.Integrated circuit, easy to install and remove
11.Dome light system provides better vision for doctors
12.Built-in battery, can work more than two hours
13.Just set the weight, other parameters are automatically calculated
Main Unit：| Working Mode | Closed,half-closed,half-open,open |
| Driven mode | Pneumatically and electrically |
| Application | 0.5-100kg animal |
| Pressure Gas Gauge | one is oxygen source pressure one is oxygen working |
| Oxygen flush | 25L/min~75L/min |
| Gas source pressure | O2:0.25Mpa~0.65Mpa |
| Power | 220V±10%,50HZ±1% or 110V±10%,60HZ±1% |
（veterinary anesthesia workstation）
| Flow meter | |
| O2 Two tube flowmeter | Two tube:0~1L/min, 1~10L/min |
| O2& Air Flowmeter Optioanl O2&N2O& Air Flowmetr Optiaonl | |
（veterinary anesthesia workstation）
| Circle Absorer | |
| Integrated and sterilized at 134°C high temperature and high pressure. Visiable inspiration valve and expiration valve | |
| Safety valve pressure limit:6Kpa Quick change soda lime system Good air tightness,high reliability and minor respiratory impedance |
（veterinary anesthesia workstation）
| Anesthesia Ventilator | |
| Ventilation Mode | PCV,VCV,SPONT,DEMO |
| Bellow | 50-1600ml,0-300ml |
| Screen | 9 inches touch screen |
| Waveform | Pressure,Flow,Volume |
| Loop | PV,PF,FV |
| BPM | 1-120bpm |
| I：E | 9.9:1-1:9.9 |
| Inspiratory time | 0.1s-10.0s |
| Apnea | 0-50% |
| PEEP | Off,3-20cmH2O |
| Pressure support | 5-60cmH2O |
| Flow trigger | 0.5-20L/min |
| Pressure trigger | -1~20cmH2O |
| PSV Inspiratory terminal level | 25% |
| Monitoring | Tidal volume,breathing rate,Spontaneous breathing rate,I:E,Spontaneous minute ventilation volume，Minute ventilation peak airway pressure,Average airway pressure,PEEP,Inspiratory platform pressure,FIO2 |
| Alarm parameters | Tidal volume,Minute ventilation volume,Frequency,Airway pressure ,Continuous airway pressure,Negative pressure alarm,Apnea alarm,Air supply pressure failure alarm,Power supply alarm,Low battery alarm,Battery exhaustion alarm,Oxygen battery failure alarm,FIO2(optional),FICO2(optional) |
（veterinary anesthesia workstation）
| Vaporizer | |
| Iso,Sevo,Halo With safety lock device | |
| Concentration range: | Iso 0.2 to 5% Halo 0.2 to 5% Sevo 0.2 to 8% |
| Flow range | 0.2 to 15L/min 0.2 to 10L/min(normal usage)for concentrations>5 vol% |
| Filling volume | 340ml with dry wick 300 ml with moist wick |
| Mounting type | Selectatec compatible Cagemout cmpatiable(optional) |
| Filling type | Pour type Easy-fill(optioanal) Key-fill(optinal) |
