Veterinary anesthesia machine
DA1200V1
EXW,FCA,FOB
1 set
300set / Week
China
7Day
Dolphinmed delivery high precious veterinary anaesthesia equipment system . It is suitable for animal hospital, pet clinic and animal laboratory. This technical index of animal anaesthesia machine can meet the needs of general anesthesia and medical research on mice, dogs, cats, rabbits, monkeys, pigs, sheep and other animals in animal laboratory.
Quantity
Feature：
- Suitable for small animals, Non-breathing circuit(Jackson or Bains Absorber) is available
- With Oxygen flush function to ensure that clinical anesthesia demand and oxygen supply demand
- The CO2 absorber supports both open loop and closed loop anaesthesia design and provides independent access
- Provides an accurate oxygen flow meter with a display range of 0 to 4LPM
- Iso sevo and halo vaporizer are optional
- Selectatec-bar and quick change vaporizer mounting device
- Pop-Off with pressure release and Positive ventilation function,make animal safe
- Professional airtight breathing circuit design, provide the stable gas anesthesia
- External and reusable soda lime canister, easily watch and replace soda lime
- This vet anesthesia machine suitable for animal within 100kg
| Main Unit | |
| Working mode | closed, half-closed ,open ,half-open |
| Driving mode | Gas driving |
| Application | Animal within 100kg |
| Vaporizer | Iso ,Sevo ,Halo |
| Oxygen flush | 25L/min-75L/min |
| Gas source pressure | Oxygen 0.25Mpa-0.65Mpa |
| Airway Pressure | -30〜60CMH2O |
| Anesthesia Vaporizer | |
Concentration range | Iso : 0.2-0.5% Sevo : 0.2-8% Halo : 0.2-5% |
| Flow range | 0.2-15L/min；0.2 to 10L/min(normal usage)for concentrations>5 vol% Filling volume for agent:about 340ml with dry wick about 300 ml with moist wick |
| Mounting type | Selectatec compatible Cagemout cmpatiable(optional) |
| Flow meter | |
| Oxygen flowmeter special for veterinary | |
| Flow range | 0-5L/min |
