Veterinary Anesthesia Machine
DA1200V5
EXW,FCA,FOB
1 set
300set / Week
China
7Day
Dolphinmed delivery high precious veterinary anaesthesia equipment system . It is suitable for animal hospital, pet clinic and animal laboratory. This technical index of animal anaesthesia machine can meet the needs of general anesthesia and medical research on mice, dogs, cats, rabbits, monkeys, pigs, sheep and other animals in animal laboratory.
Quantity
Feature：
1.Integrated anesthesia machine with ventilator, saving labor costs
8.External and reusable soda lime canister, easily watch and replace soda lime
9.With Oxygen flush function to ensure that clinical anesthesia demand and oxygen supply demand
10.Anaesthesia CO2 absorber assembly has no dead angle design, fast anesthesia, rapid recovery and high precision. The CO2 absorber supports both open and close anaesthesia design and provides independent access
11.Provide a special Pop-Off valve,Occlusion design, it can connected to the exhaust gas recovery system and provide a continuous 2 cmH20 negative pressure for the reaspirato airbag /educing valve to prevent pressure to hurt the animal, ensure the animal safety
14.The hard aluminum solid shell is used, and the surface sanding treatment is adopted, so that the cleaning and disinfection are more convenient
Technical Parameters
1.Integrated anesthesia machine with ventilator, saving labor costs
2.Respiration modes include IPPV and Manual
3.Animal-specific bellows design to meet the needs of clinical scientific research4.The internal battery can be used for more than two hours
5.Suitable for small animals, Non-breathing circuit(Jackson or Bains Absorber) is available
6.Selectatec-bar and quick change vaporizer mounting device
7.Professional airtight breathing circuit design, provide the stable gas anesthesia, save anesthesia gas consumption, to ensure a clean operating room and laboratory environment8.External and reusable soda lime canister, easily watch and replace soda lime
9.With Oxygen flush function to ensure that clinical anesthesia demand and oxygen supply demand
10.Anaesthesia CO2 absorber assembly has no dead angle design, fast anesthesia, rapid recovery and high precision. The CO2 absorber supports both open and close anaesthesia design and provides independent access
11.Provide a special Pop-Off valve,Occlusion design, it can connected to the exhaust gas recovery system and provide a continuous 2 cmH20 negative pressure for the reaspirato airbag /educing valve to prevent pressure to hurt the animal, ensure the animal safety
12.Provides an accurate oxygen flow meter with a display range of 0 to 5LPM
13.Vaporizer: the output concentration is not affected by the change of flow, pressure and temperature, accurate and reliable, equipped with safety locking device to prevent anesthetic leakage. Iso,sevo and halo vaporizer are optional14.The hard aluminum solid shell is used, and the surface sanding treatment is adopted, so that the cleaning and disinfection are more convenient
15.Visible inspiration and expiration valve,easy to check breathing state
16.With fresh gas output connector specifically designed to accomodate low flow
Technical Parameters
| Ventilator | |
| Ventilation mode | IPPV,MANUAL |
| Bellow | 0-300ml,50-1500ml |
| Screen | digital display |
| Monitor parameter | Tidal volume,breathing rate,I:E,peak pressure |
| Breathing rate | 4-60bpm |
| Minute ventilation | No less than 18L/min |
| Airway pressure upper limit | 2-6kpa |
| Airway pressure lower limit | 0.5-2kpa |
| Anesthesia Vaporizer | |
| Concentration range | Iso: 0.2-0.5% Sevo: 0.2-8% Halo: 0.2-5% |
| Flow range | 0.2-15L/min 0.2 to 10L/min(normal usage)for concentration>5 vol% |
| Filling volume | 340ml with dry wick 300ml with moist wick |
| Mounting type | Selectatec Cagemout (optional) |
| Flowmeter | |
| Oxygen flowmeter special for veterinary | |
| Flow range | 0-5L/min |
